MCGV Series

MCGV series pumps are heavy-duty, foot-mounted internal gear operating pumps with multiple seal options. This series is for a broad range of applications requiring continuous duty at pressures up to 200 psi (1379 kpa). Even higher pressures are possible with high fluid viscosities at reduced operating speeds (consult factory). The MCGV series features 13 different sizes with flows to 1,600 GPM (250 m3/hr), with four materials of construction options, cast iron, ductile iron, steel externals and stainless steel. This series pumps design allow the use of packing, component seals or cartridge seals. Seal plans, including API plan 53 and 54. Pump casings can be positioned to meet common piping configurations.


Downloads

MCGV SPECS (pdf)

Download
